BV2B/9(2002 IOTA) & BV0K(2009 IOTA)
Kuei San Dao (Turtle Island)
2002 DXPedition and WPX Content
The Team (left to right) BX9AAA BV2NT BV2KI BX4AF BV2KS BO2AB BV4VF BM2AAL BV1ED BV2AH
2002 DXPedition and IOTA Content
The Team : (back) BV2KI BV1ED BX4AF BX2AB BM2CUP BV2KS BX9AAA BV2DD
(front) BV2NT BO2AB BM2AAL JR7TEQ, while BV2AH taking photo
Few Words From Bruce/BV2KI
Years ago, The small island Kuei San Dao (Turtle Island) was a military shooting range. After government shot down The military facility and open to a public for tourism, we took 5 months paper work to have permission to this small island since Oct. 2001. Due to The bad marine condition, we wait for The best time after got that permission, and took our first trip to this Island on March 2002.
We use our club call BV2B/9 as well as this summer one. The island located at N 24-50-35 / E 121-56-48, 1 KM long and 0.8 KM wide. No residential but a routing marine guard troop and tourism bureau guiders on island. We are glad to have These two trips for our first Taiwan Ham radio on this island.
Although worked out tremendous preparation, even a 6.4 degree earthquake raised on this island on 31 March and two operators was lie-down by 38.5°C heat stroke, but we have a lot of fun There.
Equipment list of BV2B/9 Turtle Island IOTA Contest 2002
No.
Item
Q'ty
unit
Spec.
1
HF Transceiver 100W
1
Set
FT990
2
HF Transceiver 100W
1
Set
FT990
3
HF Transceiver 100W
1
Set
IC-746
4
HF Transceiver 100W
1
Set
IC-746
5
HF Transceiver 100W
1
Set
IC-746
6
HF Transceiver 100W
1
Set
FT-847
7
VHF Transceiver 100W
1
Set
IC-275
8
Linear AMP. 500W
2
Set
FL-7000
9
Linear AMP. 1KW
1
Set
SB1000
10
Linear AMP. 3500W
1
Set
HL350V
11
PWR SUPPLY
3
Set
60A
12
PWR SUPPLY
2
Set
30A
13
2 ele Cubic Quad
1
Set
GEM QUAD(5 Bands)
14
TriBand YAGI
1
Set
Comet 433
15
VHF YAGI
1
Set
2x209
16
Vertical Ant./Mast
1
Set
CUSHCRAFT/R7
17
Vertical Ant./Mast
1
Set
>HF9V, 160m~6m
18
Vertical Ant./Mast
1
Set
29/50
19
Vertical Ant./Mast
1
Set
SE50
20
Dipole & Kits
1
Set
40M/160~80
21
ANT Tuner
1
Set
Smart Tuner
22
ANT Tuner
1
Set
MFJ 1.5kw
23
ANT Tuner
1
Set
For FT-847
24
Bandpass Filter
2
Set
1.9 ~ 29.7Mhz
25
Boom Mike
5
Set
BM-10/HC5/HC4
26
Alum. Crank_up Mast.
1
Set
12M hight
27
Mast 1" O.D./6M
3
pcs
28
Mast (Telescop Type)
2
pcs
10 ~ 15M,Alum.
29
CABLE/30/40/50M
10
Pcs
RG213/FD8D
30
Link Cable
20
Pcs
31
PWR Cable 50M
2
Roll
32
Copper wire
1
Set
For Dipole & Mast.
33
Rope 10mmDia.
1
Set
Incl. Driller&Bolts
34
Tool Box & Accs.
1
35
SSTV Kit
36
SSTV Software
37
SSTV Notebook
4
38
Log Notebook
1
Operator : BM2AAL BM2CUP BO2AB BV1ED BV2AH BV2DD BV2KI BV2KS BV2NT BX2AB BX4AF BX9AAA JR7TEQ
台北市業餘無線電促進會
